Thank you, Yuri.
The certificate bundle does exist in the assumed path.
Any other suggestions would be appreciated.
Best,
RoC
The obvious thing: do you have sources for DoT? I.e.,
forward-zone:
name: "."
forward-addr: 1.1.1.1@853#cloudflare-dns.com
forward-addr: 1.0.0.1@853#cloudflare-dns.com
forward-addr: 9.9.9.9@853#dns.quad9.net
forward-addr: 149.112.112.112@853#dns.quad9.net
forward-tls-upstream: yes
?
Your Unbound should forward queries to somewhere.
02.04.2019 22:15, rollingonchrome via Unbound-users пишет:
Thank you, Yuri.
The certificate bundle does exist in the assumed path.
Any other suggestions would be appreciated. Below is my config file. Also, here is the error from the log file:
Apr 2 09:25:13 raspberrypi_pi-hole unbound[6522]: /etc/unbound/unbound.conf.d/pi-hole.conf:96: error: unknown keyword ‘tls-cert-bundle’
Apr 2 09:25:13 raspberrypi_pi-hole unbound[6522]: /etc/unbound/unbound.conf.d/pi-hole.conf:96: error: stray ‘:’
Apr 2 09:25:13 raspberrypi_pi-hole unbound[6522]: /etc/unbound/unbound.conf.d/pi-hole.conf:96: error: stray ‘"’
Apr 2 09:25:13 raspberrypi_pi-hole unbound[6522]: /etc/unbound/unbound.conf.d/pi-hole.conf:96: error: unknown keyword ‘/etc/ssl/certs/ca-certificates.crt’
Apr 2 09:25:13 raspberrypi_pi-hole unbound[6522]: /etc/unbound/unbound.conf.d/pi-hole.conf:96: error: stray ‘"’
Apologies for partially posting this message twice. I wasn’t sure exactly how to edit the subject to properly thread my reply.
server:
If no logfile is specified, syslog is used
logfile: “/var/log/unbound/unbound.log”
verbosity: 0
port: 5353
do-ip4: yes
do-udp: yes
do-tcp: yes
May be set to yes if you have IPv6 connectivity
do-ip6: no
Use this only when you downloaded the list of primary root servers!
root-hints: “/var/lib/unbound/root.hints”
Trust glue only if it is within the servers authority
harden-glue: yes
Require DNSSEC data for trust-anchored zones, if such data is absent, the zone becomes BOGUS
harden-dnssec-stripped: yes
Don’t use Capitalization randomization as it known to cause DNSSEC issues sometimes
see https://discourse.pi-hole.net/t/unbound-stubby-or-dnscrypt-proxy/9378 for further details
use-caps-for-id: no
Reduce EDNS reassembly buffer size.
Suggested by the unbound man page to reduce fragmentation reassembly problems
edns-buffer-size: 1472
TTL bounds for cache
cache-min-ttl: 3600
cache-max-ttl: 86400
Perform prefetching of close to expired message cache entries
This only applies to domains that have been frequently queried
prefetch: yes
One thread should be sufficient, can be increased on beefy machines
num-threads: 1
Ensure kernel buffer is large enough to not lose messages in traffic spikes
so-rcvbuf: 1m
Ensure privacy of local IP ranges
private-address: 192.168.0.0/16
private-address: 169.254.0.0/16
private-address: 172.16.0.0/12
private-address: 10.0.0.0/8
private-address: fd00::/8
private-address: fe80::/10
New configuration items
qname-minimisation: yes
fallback-enabled: yes
DNS over TLS: https://www.reddit.com/r/pihole/comments/969vhh/any_downside_to_using_unbound_with_dns_over_tls/
access-control: 10.0.0.0/8 allow
access-control: 127.0.0.0/8 allow
access-control: 192.168.0.0/16 allow
hide-identity: yes
hide-version: yes
minimal-responses: yes
rrset-roundrobin: yes
ssl-upstream: yes
forward-zone:
name: “.”
Quad9
forward-addr: 2620:fe::fe@853#dns.quad9.net
forward-addr: 9.9.9.9@853#dns.quad9.net
forward-addr: 2620:fe::9@853#dns.quad9.net
forward-addr: 149.112.112.112@853#dns.quad9.net
Cloudflare DNS
forward-addr: 2606:4700:4700::1111@853#cloudflare-dns.com
forward-addr: 1.1.1.1@853#cloudflare-dns.com
forward-addr: 2606:4700:4700::1001@853#cloudflare-dns.com
forward-addr: 1.0.0.1@853#cloudflare-dns.com
Google Public DNS
forward-addr: 2001:4860:4860::8888@853#dns.google
forward-addr: 8.8.8.8@853#dns.google
forward-addr: 2001:4860:4860::8844@853#dns.google
forward-addr: 8.8.4.4@853#dns.google
Cleanbrowsing Security Filter
forward-addr: 2a0d:2a00:1::2@853#security-filter-dns.cleanbrowsing.org
forward-addr: 185.228.168.9@853#security-filter-dns.cleanbrowsing.org
forward-addr: 2a0d:2a00:2::2@853#security-filter-dns.cleanbrowsing.org
forward-addr: 185.228.169.9@853#security-filter-dns.cleanbrowsing.org
Tenta DNS
ICANN
forward-addr: 99.192.182.200@853#iana.tenta.io
forward-addr: 99.192.182.201@853#iana.tenta.io
OpenNIC
forward-addr: 99.192.182.100@853#opennic.tenta.io
forward-addr: 99.192.182.101@853#opennic.tenta.io
tls-cert-bundle: “/etc/ssl/certs/ca-certificates.crt”
tls-cert-bundle feature not available until Unbound 1.7.1
Actually secure DNS over TLS in Unbound https://www.ctrl.blog/entry/unbound-tls-forwarding
request upstream over TLS (with plain DNS inside the TLS stream). # Default is no. Can be turned on and off with unbound-control. # tls-upstream: no Non-required, but parameter error for 1.9.x Ok, do you have 853 port open to outside on firewall? Can you connect from device to any upstream using telnet via 853 port?
Make sure you can connect to DoT upstream:
https://i.imgur.com/Andpr9t.png
Note: It can be blocked by your ISP or youself on firewall.
BTW. You sure you using latest 1.9.x version of Unbound? Because of real 1.9.1 should not blame on this keywords.
Hi Yuri,
Thank you for your help. Yes, 853 is open. I can see in the log files that Unbound is making SSL connections, though they are not authenticated.
I believe the problem is the tls-cert-bundle keyword or syntax:
tls-cert-bundle: “/etc/ssl/certs/ca-certificates.crt”
I am getting the following errors when that line is included in my config file:
Apr 2 09:25:13 raspberrypi_pi-hole unbound[6522]: /etc/unbound/unbound.conf.d/pi-hole.conf:96: error: unknown keyword ‘tls-cert-bundle’
Apr 2 09:25:13 raspberrypi_pi-hole unbound[6522]: /etc/unbound/unbound.conf.d/pi-hole.conf:96: error: stray ‘:’
Apr 2 09:25:13 raspberrypi_pi-hole unbound[6522]: /etc/unbound/unbound.conf.d/pi-hole.conf:96: error: stray ‘"’
Apr 2 09:25:13 raspberrypi_pi-hole unbound[6522]: /etc/unbound/unbound.conf.d/pi-hole.conf:96: error: unknown keyword ‘/etc/ssl/certs/ca-certificates.crt’
Apr 2 09:25:13 raspberrypi_pi-hole unbound[6522]: /etc/unbound/unbound.conf.d/pi-hole.conf:96: error: stray ‘"’
It looks like either my syntax is incorrect or Unbound is not recognizing the tls-cert-bundle keyword.
Thank you,
RoC
Wait. What openssl version you have?
Hi Yuri,
I have OpenSSL version 1.1.0j 20 Nov 2018
Thanks,
RoC
Yuri yvoinov at gmail.com Tue Apr 2 19:26:33 CEST 2019
02.04.2019 23:10, rollingonchrome via Unbound-users пишет:
Hi Yuri,
Thank you for your help. Yes, 853 is open. I can see in the log files
that Unbound is making SSL connections, though they are not authenticated.
Wait. What openssl version you have?
Hm. Seems ok.
Well. Finally, let’s check most obvious thing.
Show output for
unbound-control | grep Version
Hi Yuri,
pi@raspberrypi_pi-hole:~ $ unbound-control | grep Version
Version 1.9.2
I compiled 1.9.2 over 1.6.0 and doing this did not replace my config files. So there could be an issue lurking in one of those files from the original 1.6.0 installation.
Yuri yvoinov at gmail.com
Tue Apr 2 19:40:28 CEST 2019
Previous message (by thread): TLS certificate question about Unbound 1.9.2
Hm. Seems ok.
Well. Finally, let’s check most obvious thing.
Show output for
unbound-control | grep Version
We cloned from GitHub. It showed 1.9.1 as the latest but when it compiled it said 1.9.2.
Ah. You risky
Take stable. Im running stable 1.9.1 on 3 production servers exclusively with DoT, with openssl 1.0.2o and have no issues.
Also, of course, re-write unbound.conf. From 1.6.0 to 1.9.x eternity has passed.
Despite backward compatibility, the versions are still too different.
In any case, I advise you to get a stable latest released version 1.9.1.
PS. It is bad idea use unstable (when working in progress) from github and trying to use. This is very risky and usually for experienced programmers, who know what they are doing.
My high-school aged son is the expert and he was more facile with GitHub than the SVN repository.
We will have to figure out how to compile the stable version.
Thank you for your help!
Yuri yvoinov at gmail.com
Tue Apr 2 20:37:03 CEST 2019
Previous message (by thread): TLS certificate question about Unbound 1.9.2
Ah. You risky Take stable. Im running stable 1.9.1 on 3 production
servers exclusively with DoT, with openssl 1.0.2o and have no issues.
Also, of course, re-write unbound.conf. From 1.6.0 to 1.9.x eternity has
passed.
Despite backward compatibility, the versions are still too different.
In any case, I advise you to get a stable latest released version 1.9.1.
PS. It is bad idea use unstable (when working in progress) from github
and trying to use. This is very risky and usually for experienced
programmers, who know what they are doing.
You’re welcome
And make sure you really installed built binaries.
Thanks again, Yuri.
I’m still having problems. As a reminder, I’m on Raspbian which only has a 1.6.0 stable package.
I downloaded and built the 1.9.1 source code from here: http://www.unbound.net/downloads/unbound-1.9.1.tar.gz
The build is verified as Version 1.9.1.
It works fine (exactly as on 1.6.0 and 1.9.2) WITHOUT the “tls-cert-bundle” keyword.
With the “tls-cert-bundle” keyword, I continue to get this error and nothing works. It appears that unbound doesn’t recognize the “tls-cert-bundle” keyword:
pr 2 15:06:51 raspberrypi_pi-hole systemd[1]: Started Unbound DNS server via resolvconf.
Apr 2 15:06:51 raspberrypi_pi-hole unbound[27172]: /etc/unbound/unbound.conf.d/tls-cert-bundle.conf:4: error: unknown keyword ‘tls-cert-bundle’
Apr 2 15:06:51 raspberrypi_pi-hole unbound[27172]: /etc/unbound/unbound.conf.d/tls-cert-bundle.conf:4: error: stray ‘:’
Apr 2 15:06:51 raspberrypi_pi-hole unbound[27172]: /etc/unbound/unbound.conf.d/tls-cert-bundle.conf:4: error: stray ‘"’
Apr 2 15:06:51 raspberrypi_pi-hole unbound[27172]: /etc/unbound/unbound.conf.d/tls-cert-bundle.conf:4: error: unknown keyword ‘/etc/ssl/certs/ca-certificates.crt’
Apr 2 15:06:51 raspberrypi_pi-hole unbound[27172]: /etc/unbound/unbound.conf.d/tls-cert-bundle.conf:4: error: stray ‘"’
Apr 2 15:06:51 raspberrypi_pi-hole unbound[27172]: read /etc/unbound/unbound.conf failed: 5 errors in configuration file
Apr 2 15:06:51 raspberrypi_pi-hole unbound[27172]: [1554242811] unbound[27172:0] fatal error: Could not read config file: /etc/unbound/unbound.conf
Yuri yvoinov at gmail.com
Tue Apr 2 21:43:19 CEST 2019
Previous message (by thread): TLS certificate question about Unbound 1.9.2
You’re welcome
And make sure you really installed built binaries.
Does anyone know what version of TLS Unbound 1.9.1 uses?
It looks like OpenSSL on Debian/Raspbian will only support TLS 1.2 until the next Debian/Raspbian release (Buster).
Unless Unbound uses TLS 1.2, I don’t think TLS will work properly on Debian/Raspian.
Hi,
When I add some garbage to my config:
Yes, Tom, yesterday I had same question Probably you right.
03.04.2019 13:31, Tom Hendrikx via Unbound-users пишет:
